fresadoras madera usadas para la venta (594)

Helma Twinhead CopyShaper with 2 heads CF40 Copy shaper

Paoloni T140 table spindlemoulder Manufacturer: Paoloni Type: T140 Motor: 5 KW Spindle diameter: 30 mm Spindle elevation: 140 mm Rotation speed: 3000-4500-6000-9000 Spindel elevation: Handwheel with analog clock Feeder: HolzHerr 3 rollen Fence: Aigner integraal aanslag Condition: fully functional

Masterwood chisel mortiser Type: OMB1 (horizontal mortiser) Chissel: 2.2 kW electric movement with hydraulic drive stroke Table: electric sideward driven, with stops Fixation: 2 top/vertical hydraulic product clamp 2 horizontal hydraulic clamps

Verboom PN5 Left Manufacturer: Verboom Type: PN5 Left Year: Norm: EU-conformity Specifications: Saw: 2.2 KW top positioned aggregate; axial and radial positioning with analog reading Horizontal spindels: 2 2.2.kW, horizontal positioned spindels over each=other with Siko analog-digital counters for exact positioning 1st vertical spindel: Vertical spindle, 20040 mm, motor: 5,5 KW ; axial and radial positioning with analog reading 2nd vertical spindel: Vertical spindle, 120 mm, motor: 4,0 KW ; axial and radial positioning with analog reading Table: Large solid steel table with manual product clamps Length measurement: Analog cross cut fence extendable Swiveling, for angular jobs Dimensions: 3.5 (0.9+0.9) 1,6 m

Martin T25 Schwenkspindelfräse mit 2 Achs-elektrische Verstellung Marke: Martin Typ: T25 M-Nr.: V175170 Baujahr: 1990 Motor: 5/6 kW Schwenkung Frässpindel: -5° – +45° Fräsdorn: 30 mm Spindelhöhenverstellung: 150 mm (elektrische Einstellung) Drehzahlen: 3000/4500/6000/9000 U/min (2 Drehzahlmotor) Konus der Frässpindel: MK5 Softstarter: Automatischer Frässpindel-Anlauf/-bremsung per Drehknopf Systemsteuerung: Unteres Spindelverstellung: Elektromotorhöhenverstellung mit Analog-Auslesung Schrägstellung -5° – +45°: -5° – +45° Elektromotorschräge mit digitaler Lesart Fräsanschlag: Aigner Intergraal Anschlag Zustand: Voll funktionsfähig getestet

Martin T25 tilting table spindel moulder with 2-axl electric positioning Manufacturer: Martin Type: T25 M-Nr.: V172604 Year: 1990 Motor: 5/6 kW (2 RPM drive motor) Tilting: -5° – +45° Spindle diameter: 30 mm Spindle elevation: 150 mm (electrical adjustment) Rotation speed: 3000/4500/6000/9000 U/min (2 RPM drive motor) Spindel pick-up: MK5 Table: Table extension 2.500mm with extendable support (pull-out for wide workpieces) Softstarter: Automatic spindel softstart/- braking Control panel: Eye-level with digital read-out Spindel elevation: 150 mm elelvation electric with digital read-out Spindle tilting: ‘-5° – +45° Electric with digital read-out Feeder: Five-pole socket via central control Condition: Fully functional Optional: Aanvoerapparaat: Not included Aigneraanslag: Not included

Panhans 261 Tenoner Manufacturer: Panhans Type: 261 Year: 1987 M-Nr.: 1112 Specifications: Saw: 2.6 KW, 3.000 rpm, Tooldiam.: ø400 mm, spindellength 160 mm vertical spindel: 7.5 KW, 4.000 rpm, Tooldiam.ø400 mm, tenon length 170 mm, Spindellength: 160 mm Table: Solid steel table with pneumatic product clamps 80 mm adjustable Fence: Swiveling, for angular jobs Dimensions: ca. 1.9 m 1.6 m 1.7 m, plus Tenon table: 0,50,8 Meter 600 KG Condition: Fully functional

Okoma PN 2 Tenoner Manufacturer: Okoma Type: PN2 Year: M-Nr.: Specifications: Saw: 3,0 KW, 2.800 rpm, Tooldiam.: ø400 mm, spindellength 140 mm, with revolver head for height-setting vertical spindel: 7.5 KW, Tooldiam.ø40 mm- 4.000 rpm, tenon dept max. 170 mm, Spindellength: 160 mm Table: Automatic feeding table, solid steel, with pneumatic product clamps Table height: 80 mm adjustable Fence: Swiveling, for angular jobs Dimensions: ca. 2.2 m x 1.6 m , 1.7 m hoch, plus Zapfentisch: 0,50,8 Meter Weight: 600 KG

CASADEI F114 spindle moulder Manufacturer: Casadei Type: F114 M-Nr.: 01-66-183 Year: 2001 Control: Spindelhoogte: handwiel verstelbaar met digitaal-analoge uitlezing Freesaanslag: handwiel met digital-analoge uitlezing Frees aanlag invoerzijde: handwiel verstelling met digitaal-analoge uitlezing (spaanafname)

Martin T26 tilting table spindel moulder with 2-ax control and 7.5 kW frequency controlled spindle RPM Manufacturer: Martin Type: T26 with 7.5 kW frequency controlled spindle RPM Machine Nr.: 20000 Year: V415216

Martin T26 tilting table spindel moulder with 2-ax electric control and 7.5/9.5 kW 2-speed motor Manufacturer: Martin Type: T26 M-Nr.: 2005 Year: V453599 Control: electrical spindel-elevation, -tilting,-feeder elevation, manual fence positioning with digital reading Control panel: machine stand Motor: 7.5/9.5 KW 2-speed motor rpm Spindel : ø40 mmSK40 plus Dornfix-quick change system Tilting: Tilting from -45 to + 45° Spindle elevation: Electric spindle elevation 150 mm; quick- and slow speed Electro-pneumatic spindle fixation for safe and easy tool change Central greasing (long life greasing) Rotation speed: 2-speed motor 7.5/9.5 kW Spindel pick-up: SK40 Dornfix quick change system Table: 1255 x 900 x 95 mm from cast iron Ax-control: 1. Digital-electric controlled spindle height setting, with automatic milling dept. Compensation when spinlde is tilted 2. Digital-electric controlled spi ...

Martin T21 Manufacturer: Martin Type: T21 Year: Motor: 4 KW Table: 1.000930 Table height: 850 mm Konus spindle: MK5 Spindel height adjustment: 150 mm RPM: 3000/4500/6000/9000 U/min Spindle: 40 mm Max. tool diam.: 250 mm Weight: 700 KG Brake: Footbrake Dust collection: ø120 ø100 mm

Martin T25 tilting table spindel moulder with 5-axl CNC control Manufacturer: Martin Type: T25 M-Nr.: V252368 Year: 1998 Motor: 7.5/9.5 kW oder 10/13 BHP, 2 RPM Dalander motor Tilting: -5° till +45° Spindel diam.: 30 mm Spindel pick-up: ISO-quick change Spindel elevation: Spindle height adjustment: 150 mm Rotation speed: 3000/4500/6000/9000 U/min Table: Table extension 2.400mm with extendable support (pull-out for wide workpieces) Control panel: CNC control at eyes height with LCD screen Spindel elevation: CNC-controlled with electric elevation (programm controlled of hand switch setting) Spindel tilting: CNC-controlled with electric tilting, angle: -5° +45° (programm controlled of hand switch setting) Fences: CNC-controlled with electric positioning vs. spindel position (programm controlled of hand switch setting) CNC-controlled with electric positioning infeed vs. outfeed fence (pr ...

MARTIN T27 FleX with 4-ax CNC control + 5-ax manual controlled but integrated in central control + electric feeder elevation Year: 2007 Tilting: from -46° to +46° T27FX/1-a: T27 FleX tilting spindle moulder CE-norm with 7,5KW/10 HP motor and variable speed – frequency controlled CNC controlledspindle elevation CNC controlled tilting with automatic height adjustment when tilted T2704-a: Motor 9,5KW/13 HP motor and variable speed – frequency controlled rpm 1.000 – 12.000 tpm., incl. collission control T2711-a: Infeed fence manually controlled with digital counter, whereas position is integrated in central control linked T2712-a: CNC controlled fence positioning (left& right hand-side combined) T2714-a: CNC controlled table opening (programm integrated for tools Ø70 upto 250 mm T2715-a: Electric controlled feeder elevation-product thickness T2731-a: Table extension at infeed-outfee ...

Martin T26 tilting table spindle moulder with CNC 4-ax control Manufacturer: Martin Type: T26 CNC Year: 2002 Control: 4-ax CNC Control Control panel: eye-level Remark: Special paint Martin 75 Years Ral 7035& 6004 Motor: 7.5/9.5 kW – twin-speed motor Tilting: -45 tot + 45° Spindel diam.: ø40 mm spindel SK40 – Dornfix-quick change Spindel elevation: Electric spindel elevation 150mm (2 speed) Spindel elevation Electric-pneumatic spindel lock (Tool changing) Central greasing Rotation speed: Twin-speed 3000-6000 rpm or 4.500-9000 rpm, electronic display, electric -automatic brake Spindel pick-up: Dornfix-quick change spindel Table: Table extension, infeed and outfeed 2405mm long, frontside support 3000mm long, frontside extension 700mm Control panel: 1. CNC-controlled spindel elevation, with automatic dept and height control when spindle is tilted 2. CNC-controlled spindel tilting, with ...

Panhans 245 Easy Tilting spindlemoulder Manufacturer: Panhans Type: 245 Easy M-Nr.: 3003 Year: 2008 Control: 2-ax electrical controlled, spindle elevation and -swivelling, Handwheel controlled rearfences vs. spindel with digital counter reading and handwheel controlled right vs. left fence setting with digital counter. Control panel: Eye level, ergonomic turning Remark:

MARTIN T27 FLEX tilting table spindle mouder: +/- 46º plus 2 CNC controlled axes Brand: Martin Type: T27Flex M-Nr.: V528804 Year: 2014 Specifications: Frame: Composite structure: Steel outer walls filled with a steel-concrete composite structure providing the best stability, stiffness ande high vibration absorption capabillities Weight: ca. 1.450 kg Table dimensions: 1255 x 900 x 95 mm., cast-iron Working height: 900 mm Tool opening-table: 255/205/161/106/74 mm. diam. Tools with max diam. Ø 250 mm (max. 150 mm. when tilted 45º) under table level elevation RPM: 3.000, 4.000, 5.000, 6.000, 8.000, 10.000 rpm RPM-adjustement: Frequency controlled Control panel at eye level, turning for highest operator comfort Control: PowerPC-controll industrial controll, equipped with Linux TFT Touchscreen Controll panel with 216 colours), CAN-controlled servo-motoric driven axes for highest repeatabili ...

Martin T26 tilting table spindel moulder with 2-ax control and 7.5 kW frequency controlled spindle RPM and tenon table Manufacturer: Martin Type: T26FleX M-Nr.: 2000 Year: V409217 Control: Control at eye level: spindel-elevation, -tilting, infeed fence positioning, rpm-setting Control panel: Panel at eye-level, swivelling for operator comfort Motor: 7.5kW (10 BHP) with frequency controlled motor rpm Spindel : SK40 plus Dornfix-quick change system Tilting: Tilting from -45 to + 45° Spindle elevation: Electric spindle elevation 150 mm; quick- and slow speed Spindle elevation referencing tool 0-position Electro-pneumatic spindle fixation for safe and easy tool change Central greasing (long life greasing) Rotation speed: Frequency controlled 7.5 kW Spindel pick-up: SK40 Dornfix quick change system Table: Table ext6ension infeed side and tenontable outfide, that can also be used as table ext ...

Martin T26 tilting table spindel moulder with 2-ax control and 7.5 kW frequency controlled spindle RPM Manufacturer: Martin Type: T26 M-Nr.: 2000 Year: V415216 Control: Control at eye level: spindel-elevation, -tilting, infeed fence positioning, rpm-setting Control panel: Panel at eye-level, swivelling for operator comfort Motor: 7.5kW (10 BHP) with frequency controlled motor rpm Spindel : SK40 plus Dornfix-quick change system Tilting: Tilting from -45 to + 45° Spindle elevation: Electric spindle elevation 150 mm; quick- and slow speed Spindle elevation referencing tool 0-position Electro-pneumatic spindle fixation for safe and easy tool change Central greasing (long life greasing) Rotation speed: Frequency controlled 7.5 kW Spindel pick-up: SK40 Dornfix quick change system Table: Table length 2.40 mm, width: 700 mm front-side extendable Achs-control: 1. Digital-electric controlled spin ...

Este centro de procesamiento CNC Felder Format4 H100 de 4 ejes fue fabricado en 2025. Cuenta con una mesa espaciosa de 3100 x 2100 mm e incluye un cambiador de herramientas lineal de 16 posiciones, 12 husillos verticales de perforación y una sierra de ranuras. Si buscas capacidades de mecanizado CNC de alta calidad, considera la máquina Felder Format4 H100 que tenemos a la venta. Contáctanos para más detalles.

Este VITAP Point K2 TOP 2.0 de 3 ejes se fabricó en 2018. Cuenta con mecanizado continuo con un peso máximo de 80 kg y dimensiones de Y 1200 mm y Z 50 mm. La máquina incluye un cambiador automático de herramientas de 4 estaciones y un láser de referencia doble â0 para posicionamiento preciso. Si buscas capacidades CNC de alta calidad, considera la máquina VITAP Point K2 TOP 2.0 que tenemos a la venta. Contáctanos para más detalles.

Moldeadora WEINIG, tipo Unimat 23E (línea azul), año de fabricación 1998, Especificaciones de la máquina:, - Ancho de cepillo 230 mm, - Altura de cepillo 120 mm, - Alimentación por cardan, motor 4 kW, - Velocidad de avance 6 – 36 m/min, Disposición del husillo:, 1. Husillo horizontal inferior, 7,5 kW, 2. Husillo vertical derecho, 11 kW, 3. Husillo vertical izquierdo (con el nº 2), 4. Husillo superior horizontal, 11 kW, 5. Husillo superior horizontal, 11 kW, 6. Husillo horizontal inferior, 11 kW, - Mesa de superficie 2500 mm, - Frenos de motor, - Mesa ranurada, - Rodillos de mesa alimentados, - Bomba de ceralita, - Diámetro del husillo 40 mm, - Completa con herramientas y accesorios

Moldeador WEINIG, tipo Profimat 22N

Moldeador MIDA, tipo P4E

Línea de junta con dedos Grecon, tipo FL 10, año de fabricación 2010, para juntas horizontales, 10 ciclos/min, con motores de puntería en la parte superior e inferior para uniones a tope, longitud de entrada 1800 – 6000 mm, longitud de salida 2000 – 13600 mm, compuesta por: - Cinta transportadora de cadena, - Polipasto inclinable, - Alimentador de una sola pieza, - Sierra transversal Dimter 450, - Línea de unión con dedos Grecon FL-10, - Sistema de aplicación de pegamento sin contacto Oest, - Prensa ciclista con sierra de corte transversal, - Salida con estación de curado, - Sierra de varios cortes en funcionamiento continuo, - Unidad de apilamiento, - Salida para paquetes de madera

Cantor de astillado PRIMUNINI, tipo WSA

Fresadora de biselado H&M para tableros de palets

capacidad de potencia: - kWvoltio: - Vamperio: Arequisito de potencia total: kWpeso de la máquina aprox.: tdimensiones de la máquina aprox.: m

Marca: Sicar Tipo: Banco de fresado de madera + extracción Modelo: SF70 Número de bastidor: BO400062003 Año de construcción: 2003 Peso: 0,28 toneladas Longitud mm: 2500 Ancho mm: 1000 Altura mm: 1700 Dimensiones de transporte L x W x A: 2,5 x 1,0 x 1,7 Estado de la máquina : Bueno

This 3-axis SCM Morbidelli N100 22-31 PROSPACE was manufactured in 2022. It features a powerful 9.5 kW electrospindle, a full nesting table, and a 13-position linear automatic tool changer. The machine is equipped with two vacuum pumps and an automatic tool length measurement system, making it suitable for various applications such as nesting, drilling, and milling. If you are looking to get high-quality CNC processing capabilities, consider the SCM Morbidelli N100 22-31 PROSPACE machine we have for sale. Contact us for further details.
