58 UNION maquina usada para la venta

Control Heidenhain TNC 426 Mach.no. 11648 Mesa 1.600 x 1.250 mm Diámetro del husillo: 130 mm Cono ISO 50 Recorrido transversal (X) 2.000 mm Cabezal de recorrido vertical (Y) 1.600 mm Recorrido longitudinal (Z) 1.050 mm Recorrido horizontal del husillo (W) 850 mm RPM 4 – 1,120 kW 45 Voltios 380 Ciclos 50 Incluido: Peso de la máquina 26,3 ton

Heidenhain TNC 426 Mesa 1600 x 2000 mm Carga máx. 12.500 kg Diámetro del husillo: 130 mm Cono ISO 50 Recorrido transversal (X) 3.500 mm Cabezal de recorrido vertical (Y) 1.600 mm Recorrido longitudinal (Z) 1.250 mm Recorrido horizontal del husillo (W) 850 mm RPM 4 – 1,120 kW 45 Voltios 380 Ciclos 50 Incluido: Cabezal de refrentado Ø 720 mm Recorrido de la corredera del cabezal de refrentado 240 mm Peso de la máquina 31,1 ton

Key data: 102 mm, 1530 mm, 900 mm

Diámetro del husillo Ø 102 mm Cono ISO 50 Recorrido horizontal del husillo 710 mm Recorrido transversal (X) 1.530 mm Cabezal de recorrido vertical (Y) 900 mm Recorrido longitudinal (Z) 1.500 mm Mesa 1.250 x 1.400 mm R.P.M. 8 – 1.600 (18x) kW 11 Voltios 380 Ciclos 50 Incluido: Lectura digital

diámetro del husillo: 130 mm x-recorrido: 7000 mm y-recorrido: 2000 mm taper ISO: 50 eje w: 1100 mm z-eje: 350 mm tensión: 400 V reque de potencia total: 30 kW peso de la máquina ca.: . t dimensiones de la máquina ca.: .m Cabeza de fresadouniverso Heidenhain D.R.O.

Código 61080 Descripción Barrenador horizontal de la mesa Hacer UNIÓN Modelo BFT 90/3 en Número de serie 25 742 Año 1979 ( 1980 en uso ) Control Heidenhain TNC 121 Husillo 102 mm Cono del husillo ISO 50 Husillo de salida (an.) 710 mm Tabla 1400 x 1250 mm Cruz (X) 1000 mm Longitudinal (Z) 1600 mm Vertical (Y) 1000 mm Distancia mesa-husillo 0 – 1000 mm Peso sobre la mesa 3000 kg 24 Velocidades de husillo 8 - 1600 rpm Alimentación 1 - 3000 mm/min Rápidos 3 m/min. Motor 11 kW 380 Voltios Accessoiries 3 x DRO Heidenhain ( X-Y-Z ) Sujeción de la herramienta Protección de la guía Control pendel Equipos de refrigeración Opción ( precio extra ) Fresado universal con brecha de 600 mm

Código 71145 Descripción Barrenador horizontal de la mesa Hacer UNIÓN Modelo BFT 80 / 3-1 Número de serie 18301 / 34 Año 1986 Husillo 80 mm Cono de husillo ISO 40 Husillo de salida (an.) 710 mm Tabla 1120 x 1000 mm Cruz (X) 1000 mm Longitudinal (Z) 1600 mm Vertical (Y) 1000 mm Distancia mesa-husillo 0 – 1000 mm 24 Velocidades de husillo 8 - 1600 rpm Alimentación 1 - 2500 mm/min Rápidos 3 m/min. Motor 11 kW 380 Voltios Tamaño L x W x H 5500 x 3200 x 2800 mm Weigth 9 tonelada Accessoiries Cabezal de cara 460 mm con carrera de 180 mm 3 x DRO Heidenhain ( X-Y-Z ) Sujeción de la herramienta Protección de la guía Control pendel Equipos de refrigeración Opción ( precio extra ) Fresado universal La máquina de acondiciona está en buenas condiciones

BFT 90/3 SPINDEL 102 , ISO

spindle diameter:130 mm spindle diameter:130 mm x-travel:2190 mm y-travel:1520 mm z-travel:1000 mm w-axis:1075 mm table surface area:2000 x 1800 mm workpiece weight max.:8000 kg spindle turning speed range:4,5 x 900 U/min spindle taper: ISO:50 faceplate turning speed range:4,5 x 180 U/min faceplate diameter:785 mm rapid traverse::5000 mm/min total power requirement:40 kW weight of the machine ca.:35 t dimensions of the machine ca.:5,5 x 6,9 x 5,2 m Machine retrofit and overhould with TNC 360 Heidenhain in 2023 and stepless spindle speeds - table indexing 4 x 90° - facing head 785 mm - exhauster - various arbors and tooling

spindle diameter:130 mm x-travel:2190 mm y-travel:1520 mm z-axis:1520 mm w-axis:1000 mm table surface area:2000 x 1800 mm workpiece weight:8 t spindle motor:18 kW spindle taper ISO:50 spindle turning speed range:4,5 - 900 U/min faceplate diameter:785 mm rapid traverse:5 m/min total power requirement:40 kW dimensions of the machine ca.:5,5 x 6,9 x 5,2 m weight of the machine ca.:35 t Machine was retrofitted in 2023 with HEIDENHAIN TNC 360 CNC control - inf. variable spindle spped - 4 x 90° table positioning - diverse toolholders - dDust exhauster

spindle diameter: 125 mm spindle travel: 1130 mm column travel: 6000 mm headstock travel cross: 1700 mm column travel on cross-slide: 400 mm spindle speeds: 2,24 - 450 (27x) U/min volt: 380 V total power requirement: 14 kW weight of the machine ca.: t dimensions of the machine ca.: m Facing head D.R.O. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

spindle diameter: 125 mm spindle travel: 1000 mm column movement horizontal: 7000 mm headstock - vertical: 2500 mm/min cross travel column: 450 mm taper ISO: ISO 50 P.D.B. total power requirement: 25 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Diámetro del husillo: - mmx - recorrido: 1600 mmy - recorrido: - mm Consumo total de potencia: - kWweight de la máquina aprox. 13,7 tDimensiones de la máquina ca.: - m Los datos de este anuncio se crearon con ModulMWS, la solución de software de LogoTech oHG.

spindle diameter: 130 mm x-travel: 6500 mm y-travel: 2000 mm z-travel: 900 mm W-axis (spindle longitudinal): 800 mm spindle motor: kW spindle turning speed range: 5 - 1000 U/min total power requirement: 30 kW weight of the machine ca.: 35,5 t dimensions of the machine ca.: - m - Spindle mount: SK 50 - Table size: 1800 x 2000 mm,10t - Angle head - Faceplate with faceplate slide U: 320 mm, - Heidenhain digital Readout, - Counterholder - 2 plate fields The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 3000 mm y-travel: 2000 mm z-travel: 1600 mm spindle diameter: 150 mm spindle taper ISO: 50 spindle stroke: 700 mm spindle turning speed - stepless: 5 - 2500 U/min rapid traverse: 10000 mm/min table surface area: 1600 x 2000 mm workpiece weight: ca. 20 t spindle drive motor: 50 kW feeds x/y/z -stepless: 1 - 9999 mm/min table positioning: 360.000 ° total power requirement: ca. 70 kW weight of the machine ca.: 40 t dimensions of the machine ca.: 6,0 x 8,0 x 4,5 m Horizontal drilling and milling machine / machining centre in cross-table design with: 2005 new 5-axis CNC control Dr. Heidenhain TNC 430 - electronic handwheel HR 410 for all axes with V24 interface, punched tape reader, new electrics, new hydraulics, new servo motors, measuring probe for workpiece measurement - 60-position chain tool changer model WM III k02 - B-axis (table rotary adjustment) 360,000 ° - IKZ - interna ...

Key data: 102 mm, 1600 mm, 1250 mm

Diámetro del husillo Ø 102 mm Cono ISO 50 Recorrido horizontal del husillo 710 mm Recorrido transversal (X) 1.600 mm Cabezal de recorrido vertical (Y) 1.250 mm Recorrido longitudinal (Z) 1.500 mm Mesa 1.250 x 1.400 mm Carga de la mesa 5 ton R.P.M. 4 – 1.250 (18x) kW 23 Voltios 380 Ciclos 50

Key data: 102 mm, 1600 mm, 900 mm

Diámetro del husillo Ø 102 mm Cono ISO 50 Recorrido horizontal del husillo 710 mm Recorrido transversal (X) 1.600 mm Cabezal de recorrido vertical (Y) 900 mm Recorrido longitudinal (Z) 1.520 mm Mesa 1.250 x 1.400 mm R.P.M. 8 – 1.600 (18x) kW 11 Voltios 380 Ciclos 50 Incluido: Lectura digital de 3 ejes con control punto a punto Heidenhain 310

Wire electrode, SG2 welding wire, welding wire -Net weight: 15 kg -Number: 26x package available -Price: per package -Weight complete: 15.6 kg/package

Wire electrode, SG2 welding wire, welding wire -Net weight: 15 kg -Number: 1x package available -Price: per package -Weight complete: 15.6 kg/package

Aserradero Union BFP 130/6 BJ 1982

Se vende mandrinadora de unión CBFK 150/2 de 1990. Actualmente todavía está en uso. Detalles técnicos / accesorios / adición: Recorrido X 3000 mm Recorrido en Y 2000 mm Recorrido en Z 1600 mm Diámetro del husillo 150 mm Soporte de husillo ISO 50 Carrera del husillo 700 mm Velocidades del husillo: infinitamente variables 5 - 2500 rpm Desplazamientos rápidos 10000 mm/min Área de sujeción de la mesa 1600 x 2000 mm Peso de la pieza aprox. 20 t Motor de accionamiento del husillo 50 kW Alimentaciones x/y/z - infinitamente variables 1 - 9999 mm/min Posicionamiento de la mesa 360,000 Potencia total requerida aprox. 70 kW Peso de la máquina aprox. 40 t Dimensiones aprox. 6,0 x 8,0 x 4,5 m En 2005: nuevo control CNC de 5 ejes Dr. Heidenhain TNC 430 - electrón. Volante HR 410 para todos los ejes con V24 interfaz, lector de cinta perforada, nueva electricidad, nuev ...

UNION BFK-2- Máquina perforadora de banco CNC Año de construcción : 1994 Revisión eléctrica y electrónica : 2005 Husillo : 130 mm ( Ø ) ISO 50 X : 3.000 mm Y : 1.600 mm Z : 1.200 mm (torre) W : 800 mm ( husillo ) B : 360/1° (plataforma giratoria) Mesa giratoria CNC : 2000 x 1600 mm – 12,5 T Velocidad del husillo : 2.500 rpm Motor de husillo : 30 kW Potencia total : 45 kW Peso de la máquina : 36 T (aprox.) Sistema de control Heidenhain : Heidenhain TNC530

spindle diameter: 130 mm x-travel: 3500 mm y-travel: 2050 mm z-travel: 1050 mm spindle taper ISO: 50 turning speeds: 4-1120 U/min Feed: 5-2000 mm/min bore spindle stroke: 850 mm main drive motor: 45 kW table surface area: 1600x2000 mm Control: Heidenhain type: TNC 426 workpiece weight: 12500 kg : 720 mm radial face slide travel: 240 mm : total power requirement: 90 kW weight of the machine ca.: 31,1 t dimensions of the machine ca.: 6,5x5x5x4 m Turntable with digital display The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, pleas ...

spindle diameter: 125 mm x-travel: 2360 mm y-travel: 1570 mm z-travel: 780 mm w-axis: 410 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

spindle diameter: 130 mm x-travel: 2000 mm y-travel: 1600 mm z-travel: 1000 mm spindle taper ISO: 50 turning speeds: 4-1120 U/min Feed: 5-2000 mm/min bore spindle stroke: 850 mm main drive motor: 45 kW table surface area: 1250x1600 mm Control: Heidenhain type: TNC 426 workpiece weight: 12500 kg : 720 radial face slide travel: 240 mm total power requirement: 90 kW weight of the machine ca.: 26,3 t dimensions of the machine ca.: 6,5x5x5x4 m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further of ...

Capacidad de diámetro interior en acero (diámetro): / mmx-recorrido: 1750 mmy-recorrido: 1250 mmz-eje: 1250 mmpotencia total requerida: kWpeso de la máquina aprox.: 13 tdimensiones de la máquina aprox.: mLos datos para este anuncio se crearon con ModulMWS, la solución de software de LogoTech oHG.

tamaño de la mesa: 1800 x 2000 mmLos datos para este anuncio se crearon con ModulMWS, la solución de software de LogoTech oHG.

diámetro del husillo: 110 mm peso: aprox. 130 kg Soporte de husillo usado para una perforadora de mesa, por ejemplo, UNION BFK con un diámetro de husillo de 110 mm. ¡Buen estado!
