Cizallas-guillotina DURMAZLAR MS 1303
máquinas para el procesado de metales / trabajo con chapas de metal / Cizallas-guillotina
Offer 26255 Technical data: - max. working width 1350 mm - max. cutting capacity St 40 3 mm - Cutting angle 2.30 ° - mot. Back gauge 20 - 750 mm - Pneumatically supported sheet metal elevation - Rear space protection with light barrier - Front angle stop + support arms - Stroke rate up to 42 rpm ...
Fabricante: DURMAZLAR
Modelo:MS 1303
Tipo de máquina: Cizallas-guillotina
Número de artículo: 170383882
Cantidad: 1
Fecha: 28.10.2026
Año de fabricación: 2015
Ubicación:
Alemania
63322 Rödermark
Precio:
Su propuesta de precio:
Seller-item-No.:Lg.-Nr. 26255
Offer 26255
Technical data:
- max. working width 1350 mm - max. cutting capacity St 40 3 mm
- Cutting angle 2.30 °
- mot. Back gauge 20 - 750 mm
- Pneumatically supported sheet metal elevation
- Rear space protection with light barrier
- Front angle stop + support arms
- Stroke rate up to 42 rpm depending on cutting length
- Pneumatic connection 6 bar
- Drive 400 V / 7.5 kW
- Table height approx. 850 mm
- E. footswitch
- Space requirements including back gauge and rear space protection without front support arms
- approx. W 1950 x H 1250 x D 1950 mm
- Weight approx. 1800 kg
Technical data:
- max. working width 1350 mm - max. cutting capacity St 40 3 mm
- Cutting angle 2.30 °
- mot. Back gauge 20 - 750 mm
- Pneumatically supported sheet metal elevation
- Rear space protection with light barrier
- Front angle stop + support arms
- Stroke rate up to 42 rpm depending on cutting length
- Pneumatic connection 6 bar
- Drive 400 V / 7.5 kW
- Table height approx. 850 mm
- E. footswitch
- Space requirements including back gauge and rear space protection without front support arms
- approx. W 1950 x H 1250 x D 1950 mm
- Weight approx. 1800 kg
