CNC Turning- and Milling Center MONFORTS DNC 5
máquinas para el procesado de metales / tornos
turning diameter:370 mmturning length:200 mmSpindle 1 RPM:4000 1/mincontrol:Siemens 840 D Spindle 2 RPM:4000 1/minpower capacity:L / R 18/24 kWmax. torque on the spindle:630 nMC-Axis:0,001° Turret No.1 stations / rotary tools:12/12 VDI 40Turret No.2 stations / rotary tools:12/12 VDI 40turning ...
Fabricante: MONFORTS
Modelo:DNC 5
Tipo de máquina: CNC Turning- and Milling Center
Número de artículo: 170386310
Cantidad: 1
Fecha: 28.10.2026
Año de fabricación: 2002
Ubicación: Süddeutschland
Precio:
Máquina en stock:Sí
Seller-item-No.:1070-100700
turning diameter:370 mm
turning length:200 mm
Spindle 1 RPM:4000 1/min
control:Siemens 840 D
Spindle 2 RPM:4000 1/min
power capacity:L / R 18/24 kW
max. torque on the spindle:630 nM
C-Axis:0,001°
Turret No.1 stations / rotary tools:12/12 VDI 40
Turret No.2 stations / rotary tools:12/12 VDI 40
turning speed range - milling:3000 1/min
power capacity - milling spindle:8,8 kW
torque rotary tools:28 Nm
Bar capacity spindle 1:85 mm
total power requirement:65 kVA
weight of the machine ca.:13 t
dimensions of the machine ca.:5,7x2,4x2,1 m
Travel x1:260 mm
Travel x2:260 mm
Travel Y1:600 mm
Travel y2:600 mm
Power Chuck:2 x 250 mm
manual tool eye:l & r
High performance 6-axis subspindle CNC-Lathe with twin turren and rotating tools.
turning length:200 mm
Spindle 1 RPM:4000 1/min
control:Siemens 840 D
Spindle 2 RPM:4000 1/min
power capacity:L / R 18/24 kW
max. torque on the spindle:630 nM
C-Axis:0,001°
Turret No.1 stations / rotary tools:12/12 VDI 40
Turret No.2 stations / rotary tools:12/12 VDI 40
turning speed range - milling:3000 1/min
power capacity - milling spindle:8,8 kW
torque rotary tools:28 Nm
Bar capacity spindle 1:85 mm
total power requirement:65 kVA
weight of the machine ca.:13 t
dimensions of the machine ca.:5,7x2,4x2,1 m
Travel x1:260 mm
Travel x2:260 mm
Travel Y1:600 mm
Travel y2:600 mm
Power Chuck:2 x 250 mm
manual tool eye:l & r
High performance 6-axis subspindle CNC-Lathe with twin turren and rotating tools.
