tornos usadas para la venta (3,106)

O-M LTD. Fresadora vertical CNC CONTROLES CNC FANUC 16T-A, RETROFIT 1994 CAPACIDAD: DIÁMETRO DE LA MESA 4000mm DIÁMETRO MÁXIMO DE GIRO 7000mm ALTURA MÁXIMA DE GIRO 2900mm ALTURA MÁXIMA BAJO RIEL 3000mm CAPACIDAD DE PESO DE LA MESA 45400kg RECORRIDO VERTICAL DE LA MEMORIA RAM, EJE Z 1500 mm RECORRIDO HORIZONTAL DE LA MEMORIA RAM, EJE X 2550mm RANGO DE VELOCIDADES DE LA MESA .55-40 RPM VELOCIDADES DE LA TABLA 16 PASOS RANGO DE ALIMENTACIÓN VERTICAL RAM HEAD 0.003-.6 IPR RECORRIDO RÁPIDO, CABEZAL HORIZONTAL 49 IPM RECORRIDO RÁPIDO, CRUCE FERROVIARIO 12 IPM RECORRIDO RÁPIDO, COLUMNA 21 MIP PAR MÁXIMO 58,000 LB/FT EQUIPADO CON: CONTROLES CNC FANUC 16T-A (RETROFIT 1994) MESA RANURADA EN T DE 4000 mm CON 4 MANDÍBULAS SUPERIORES COLUMNA AJUSTABLE ABIERTA ARIETE OCTOGONAL VERTICAL SOBRE RIEL TRANSVERSAL REFRIGERANTE PROTECTORES DE CHIP TRANSPORTADOR DE VIRUTAS ...

Froriep CNC Molino de mandrinado vertical Doble columna RECONSTRUIDO Y MODERNIZACIÓN CNC EN 1999 FUNCIONES: SIEMENS 840D CNC CONTROL 2 CABEZALES DE RAM VERTICALES CAPACIDAD: DIÁMETRO DE LA MESA: 10,000mm DIÁMETRO DE GIRO CON ARIETES VERTICALES: 15.000 mm ALTURA MÁXIMA DE GIRO: 5000mm RECORRIDO VERTICAL DE LA RAM: 2000 mm RAM GIRATORIO +/- 30/15 DEG FUERZA MÁXIMA DE CORTE DEL RIEL DERECHO HD: 25t CAPACIDAD DE CARGA DE LA MESA: 200t RANGOS DE VELOCIDAD DE LA TABLA, VARIABLE INF: 4 VELOCIDADES DE TABLA: 0.13 A 13 RPM MOTOR DE ELEVACIÓN DE RIEL CRUZADO: 40.23 HP NÚMERO DE ALIMENTACIONES, VERTICALES Y HORIZ: 30 MOTOR DE AJUSTE DE CARRIL CRUZADO 86 CV MOTORES DE RECORRIDO RÁPIDO: 15.5 HP MOTOR PRINCIPAL: 250 CV EQUIPADO CON: SIEMENS 840D CNC CONTROL NUEVO 1999 CONTROLES OPERADOS POR DOBLE COLGANTE 2-VERTICALES DE CARNEROS CONTROLADOS POR CNC MESA R ...

MORI SEIKI NT6600 CNC CENTRO DE TORNEADO DE MOLINO INTEGRADO CON FRESADO EN VIVO SWING MÁXIMO SOBRE LA CAMA: 42 pulgadas DIÁMETRO MÁXIMO DE LA PIEZA DE TRABAJO: 42 pulgadas LONGITUD MÁXIMA DE LA PIEZA DE TRABAJO: 239 pulgadas DIÁMETRO MÁXIMO DE LA BARRA: 6.4inch DIÁMETRO DEL HUSILLO: 7 pulgadas X AXIS TRAVEL: 41 pulgadas RECORRIDO DEL EJE Y: 26 pulgadas RECORRIDO DEL EJE Z: 242 pulgadas EJE B: +/- 120 GRADOS. VELOCIDAD DEL HUSILLO PRINCIPAL: 1500 RPM MOTOR DEL HUSILLO PRINCIPAL: 40 HP VELOCIDAD DEL HUSILLO DE FRESADO: 8000 RPM MOTOR DEL HUSILLO DE FRESADO: 40 HP ELECTRICIDAD: 220V / 3P / 60Hz / 216A OAD (APROXIMADO): 490inch X 182inch X 169inch HIGH PESO (APROXIMADO): 120,560 LBS. EQUIPADO CON: EJE C YAXIS EJE B HERRAMIENTAS/FRESADO EN VIVO CHUCK de 20 pulgadas FS-31iA5 CNC CONTROL CAMBIADOR AUTOMÁTICO DE HERRAMIENTAS DE 140 POSICIONES CULATA PROGRAMABLE  ...

TORNO GIRATORIO CNC FABRICANTE: M+M MODELO: HF450TT/2S NÚMERO DE SERIE: 26-2453-00 AÑO: 2000 FABRICANTE Y MODELO DE CONTROL: Tracktronic ALTURA CENTRAL DEL EJE Z: 419 mm DISTANCIA ENTRE CENTROS: 1200mm ADAPTADOR DE HERRAMIENTAS Z -AXIS: DIN 55027 / Tamaño 15 POTENCIA DE ACCIONAMIENTO DEL EJE Z: 80kW TASA DE REDUCCIÓN Z-AXIS DRIVE ZF: 1:4 VELOCIDAD DE ACCIONAMIENTO DEL EJE Z: 0-1000 RPM paso menos variable X - RECORRIDO DESLIZANTE: 500 mm X - FUERZA DE DESLIZAMIENTO: 100kN X - VELOCIDAD DE DESLIZAMIENTO: 400 mm / min Y - RECORRIDO DE LA DIAPOSITIVA: 275 mm Y - FUERZA DE DESLIZAMIENTO: 100kN Y - VELOCIDAD DE DESLIZAMIENTO: 400mm/min RECORRIDO DE LA CULATA: 600 mm FUERZA DE SUJECIÓN DE LA CULATA: 80kN RECORRIDO DEL EYECTOR: 450mm REFRIGERANTE: sí POTENCIA 3PHASE / 50-60 Hz / 200 - 500 Voltios: 3PH/60Hz/480V existente CARACTERÍSTICAS ESPECIALES O ARTÍCULOS ADI ...

turning diameter over bed: 280 mmturning dia. over face-slide: 150 mmcentre height: 140 mmturning length: 500 mmmain drive stepless adjustable: 0 - 6.000 U/minspindle speed: 30 - 5.000 U/minmax. workpiece weight between centers: 100 kgquill stroke: 85 mmtotal power requirement: 4 kWweight of the machine ca.: 800 kgdimensions of the machine ca.: 1430 x 950 x 1550 mmBed Slide (Z-Axis): - Guide length of the bed slide: 350 mm - Bed width: 205 mm - Slide travel: 500 mm - Max. feed force: 3500 NFlat slide (X-axis): - Slide travel: 150 mm - Slide width: 140 mm - Max. feed force: 2500 N Upper slide (Z-axis):- Slide travel: 100 mm - Slide width: 9 ...

turning diameter: 246 mmturning length: 445 mmcontrol: Siemens 840D spindle speed: 6.000 U/minrapid traverse Z-axis: 30 m/minrapid traverse X-axis: 24 m/mintailstock travel: 450 mmmax. weight between the centers: 110 kgtotal power requirement: 24 kVAweight of the machine ca.: 3,95 tdimensions of the machine ca.: 3,05 x 1,65 x 1,75 mCTX 310: - Powered tools with C-axis - TailstockWorking area: - Machine bed length: 1,625 mm - Center height: 365 mmTailstock: - Max. tailstock force: 400 daNTool holders: - Number of tools: 12 - Tool holder: VDI 30The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

number of spindles:6 spindle passage:22 mm?Bar feeder complete is 4.70 meters - for 3 meters of material ?The machine is still on ?Materail to be processed on the machine: Steel ?Production with OIL Machine has only Single-NCU without PCU.The complete energy supply of all 6 main spindles was replaced in April 25.No socket for powered tools!

number of spindles:8

weight of the machine ca.:18 tcentre distance:700 mmmax. swing diameter:200 mmLathe with 4 tools only for 3-cylinder crank shaft

max. workpiece diameter:29 mmmin. workpiece diameter:26 mmworkpiece length:66 mmthe system was originally delivered for the following workpiece sizes: diameter 26mm - 29mm length 65mm - 66mmChanging parts in the clamping device, handling, etc. would probably result in diameters of up to approx. Ø50mmTotal length will probably be almost 400 mm possible with a few conversions.Also dependent on tool lengths, machining lengths on the component, etc.Workpiece: Piston pin Drawing number: WHT 000 718, WHT 000 718 A Workpiece dimensions (Ø, WxH): Ø26 x 66; Ø29 x 65 Length: 66 or 65 mm Material: 17Cr3Quantity: xxx parts / year Cycle time: 5 sec. However, workpiece lengths up to 600mm are manageable. The machining diameter can be adjusted if the appropriate tools are available. The clamping station can currently only accommodate this product. However, this can be adapted by changing the clampi ...

turning diameter:250 mmswing diameter:250 mmturning height:200 mmtotal power requirement:37,7 kWchuck diameter:315 mmspindle speed max.:5500 1/mintravel -x axis:625 mmtravel -y axis:+100/-80 mmtravel -z axis:250 mmworktool system:VDI 30+40 weight of the machine ca.:8 tThe synchronous spindle is powered with 37.7 kW of power, a torque of 300 Nm and a maximum speed of 5,500 rpm.Typical components are ball cages, ball hubs, gear wheels, sliding sleeves,pump wheels, flanges, synchronizer rings, bearing rings and pivot pins.The machine bed is made of Hydropol, a mixture of special concrete and steel, which ensures the greatest smoothness and precision even with larger components and powerful machining.

number of spindles:6 spindle passage:18 mmturning length:63/50 mmweight of the machine ca.:8,6 tspindle drive motor:11 kW

turning diameter:200 mmturning height:120 mmweight of the machine ca.:18 tAvailable from 01.08.2024

Torreta motorizada DL-35M, control Oi-TF de la serie FANUC Excluyendo los soportes de mecanizado y herramientas DISPONIBILIDAD FINALES DE ENERO/PRINCIPIOS DE FEBRERO DE 2027 Auction-ID: A7-51034-13

turning diameter:1000 mmswing diameter:1000 mmMachine type: Vertical latheManufacturer: HessappType: DV 62Serial no.: 14.2308Working range of the spindleLargest diameter 1000 mmLargest swing diameter 1000 mmCross slide travelStroke of the vertical slide 900 mmStroke of the horizontal slide 1810 mmTotal travel 2315 mmTurning spindleSpindle head with centering cone according to DIN 55021 A15Spindle diameter in the front bearing 203 mmMain driveVia a controlled asynchronous motor and gear transmissionwith range switching.Spindle speedsSpeed range I: 5 - 350 rpm.Speed range II: 30 - 1000 rpm.Travel speedX/Z axis: 10 m/min.W1 axis: 8 rpmNo C-Axis

faceplate diameter:800 mmpower requirement:110 kWweight of the machine ca.:37.000 / total 52.000 ttransport measurements machine:5,07 x 2,98 x 3,90 mclamping diameter:800 mm:Ø 800 x 720 mmTool bore:Capto C6 tools in tool magazin:2 x 80 With C-Axis

faceplate diameter:1600 mmpower requirement:80 kWweight of the machine ca.:25 tdimensions of the machine ca.:4,4 x 4,62 mmax. workpiece diameter:2000 mmmax. diameter of face turning:1800 mmtool taper:ISO50 The machine has been regularly serviced and is in good technical condition. With C-Axis

Control FANUC Serie 32i MODELO B, con alimentador de barras TOP AUTOMAZIONI XF365 Excluyendo soportes de mecanizado, herramientas y filtro de aire superior a la máquina DISPONIBILIDAD NOVIEMBRE 2026 Auction-ID: A7-51034-20

turning diameter:270 -300 mmturning length:710 mmtotal power requirement:43 kWweight of the machine ca.:8,5 tdimensions of the machine ca.:3,16 x 2,15 x 2,15 mThe machine does not include a chuck or tools ? the machine was originally purchased without these accessories. The G300 has X, Z, Y, C, SP, and driven tools. A bar feeder can be used, but the machine does not have one.

turning diameter:220 mmturning length:310 mmtotal power requirement:17 kWweight of the machine ca.:3,3 tdimensions of the machine ca.:2,25 x 1,63 x 1940 mgreates pass round over bed:430 mmbore diameter:45 mmcentre distance:687 mmslide travel radial ( X-axis ):160 mmslide travel axial ( Z-axis ):310 mmspindle turning speed range:0-6.300 U/min

turning diameter:220 mmturning length:700 / 665 mmtotal power requirement:17 kWweight of the machine ca.:2,6 tdimensions of the machine ca.:2,63 x 1,98 x 1,94 mgreates pass round over bed:430 mmPart length max.:510 slide travel radial ( X-axis ):160 mmbore diameter:45 mmTexte, Bilder, Grafiken, Layout, Strukturen und Algorithmen etc. unterliegen weltweitem Urheberrecht.Unerlaubte Verwendung der Daten, werden sowohl strafrechtlich als auch zivilrechtlich verfolgt.Das ausschließliche Urheber- / Nutzungsrecht dieser Daten wurde nachfolgender Person eingeräumt.Copyright © 2005-2026, Josef Weber. All rights reserved.

turning diameter:360 mmturning length:520 mmtotal power requirement:20 kWweight of the machine ca.:3,8 tdimensions of the machine ca.:3 x 2 x 2 m

turning diameter:360 mmturning length:520 mmtotal power requirement:20 kWweight of the machine ca.:3,8 tdimensions of the machine ca.:3 x 2 x 2 m

turning diameter:270 mmturning length:710 mmweight of the machine ca.:6,5 tmax. swing diameter:590 mmwith automatic loading and unloading system G300 with "spindle bore clamping capacity 90mm" in tailstock versionThe machine has no driven tools. The information in the circuit diagram refers to the rotary drive for indexing the turret, not to driven tools.

turning diameter:270 mmturning length:710 mmweight of the machine ca.:6,5 tmax. swing diameter:590 mmwith live tools:VDI40 Live tooling VDI40with automatic loading and unloading system G300 with "spindle bore clamping capacity 90mm" in tailstock versionChip conveyor, belt filter press, hydraulic unit, as well as infeed and outfeed chain conveyor EWAP, with 33 pallets. The machine has no driven tools. The information in the circuit diagram refers to the rotary drive for indexing the turret, not to driven tools.

turning diameter:270 mmturning length:710 mmweight of the machine ca.:6,5 tmax. swing diameter:590 mmwith automatic loading and unloading system, chip conveyorG300 with "spindle bore clamping capacity 90mm" in tailstock versionThe machine has no driven tools. The information in the circuit diagram refers to the rotary drive for indexing the turret, not to driven tools.

Auction-ID: A1-47366-175

total power requirement:40 kWOut of valve production

turning diameter:120 mmturning length:650 mmweight of the machine ca.:11 tdimensions of the machine ca.:5,032 x 3,048 x 2,445 mGildemeister MF Twin 65-II lathe with loading automation.This machine is suitable as a counter spindle machine for 4-axis machining on the main and counter spindles, complete machining (turning, drilling, milling, Y-axis, B-axis) of bar and shaft parts.

turning diameter:120 mmturning length:650 mmweight of the machine ca.:11 tdimensions of the machine ca.:5,032 x 3,048 x 2,445 mmax. swing diameter:250 mmGildemeister MF Twin 65-II lathe with loading automation.This machine is suitable as a counter spindle machine for 4-axis machining on the main and counter spindles, complete machining (turning, drilling, milling, Y-axis, B-axis) of bar and shaft parts.
